C-UAS stands for Counter-Unmanned Aircraft System. It refers to a system or set of technologies designed to detect, track, and mitigate the threats posed by unmanned aircraft systems (UAS) or drones.
AIERIAL PLATFORM:
AN IMPERMANENT WORLD HAS BECOME A MAJOR ISSUE TODAY - "SECURING THE SKIES, SAFEGUARDING THE FUTURE."
300
2H
12
[ KM/H ]
[ ENDURACE ]
[ GAUGE]
+
FEATURED:
USEFUL:
[ WEDRONES.COM ]
Project
Drone Hunter
Drone Hunter
Counter Unmanned Aerial Systems (C-UAS)
WE PROVIDE INTEGRATED AERIAL SOLUTION, FROM SENSING TO INTERCEOPTION
WE RESEARCH AND DEVELOP AN INTEGRATED AERIAL PLATFORM TO SEARCH FOR AND ATTACK A HOSTILE UAV (FIXED - AND ROTORWING) IN STRICTLY SPECIFIED REGION.
+
2024
[ UMEX PRESENTAION ]
Q3
[ 2023 TEST FLIGHTS ]
15+
[ COUNTRIES ]
45%
[ READY]
>10
[ TEAM ]
PLATFROM
FEATURES
FEATURES
INNOVATIVE TECHNOLOGIES
KARMA
- Fixed-wing aircraft with minimum airspeed of 40 and maximum of 300
- Catapult take-off and arresting gear landing (parachute optional)
- Observed and controlled remotely by operator through radio or satellite bi-directional datalink.
AERIAL PLATFORM:
AIR NAVIGATION FEATURES:
- GNSS receiver for positioning. Catapult take-off and arresting gear landing (parachute optional)
- ADS-B Transceiver for identification and traffic collision avoidance system (TCAS)
- Onboard air navigation database with respect to all controlled and restricted airspaces and NOTAMs.
- Onboard terrain information database for terrain awareness and warning system (TAWS).
INTELLEGENCE, SURVEILLANCE, AND RECONNAISSANCE (ISR)
FEATURES:
FEATURES:
- Passive radar detector with direction finder by phase-coherent software-defined radio system to detect and get closer to the radio controlled UAV.
- Electro-optical infra-red (EO/IR) turret for visual identification and optical target marking. No laser designation used.
- Laser rangefinder for distance measurement.
INNOVATIVE TECHNOLOGIES
KARMA
- Target UAV transmission radio frequency identification.
- Closer look optical identification and human operator confirmation of the target.
- Machine learning and neural networks to classify detected targets.
TARGET IDENTIFICATION FEATURES:
TARGET ATTACK FEATURES:
- Powerful super high frequency (SHF) gun to destroy the target's electronic components. Effective distance up to 30 meters.
- Firearm gun with 12 gauge anti-drone round with a net. Effective distance up to 90 meters.
- (Optional) Firearm gun with shot (pellet).
SAFETY FEATURES:
- Human operator target confirmation.
- Strict mission area - all counter-drone actions will be held inside the specific area.
- Dual safety switch function - software and electrical.
- Built-in self test functions to detect internal systems failures.
WHY INVEST
IN US?
IN US?
[04]
investing in our company, You can benefit from being associated with a groundbreaking product that sets new standards in the drone C-UAS industry.
UNIQE OFFERING
[02]
Our dedication to utilizing composite materials and sourcing high-quality optics and engines from world leaders in the industry ensures that our drone is built to the highest standards.
QUALITY
[03]
Being the first company to develop a completely new drone C-UAS using state-of-the-art technology showcases we are pioneering spirit and commitment to innovation.
TRUST
[01]
Our team of aviation engineering professionals with long experience brings a wealth of expertise to the table.
EXPERIENCE
+
[ ABOUT ]
PLATFORM SPECIFICATION
Passive Equipment
- Radar detector
- EO/IR
- ADS-B receiver
EQUIPMENT
Active radio equipment
- ADS-B Transponder
- LiDAR or other distance measurement equipment
- Radio (or satellite) datalink
Offensive equipment:
- Super high frequency (SHF) gun
- Firearm gun of 12 gauge
+
[ ENDURACE ]
[ CEILLING ]
[ WINGSPAN ]
2h
5000m
2-3m
Type: fixed wing
Weight: 35-40 kg
Weight: 35-40 kg
INFORMATION
Maximum speed: 100 km/h (prototype) and 300 km/h (final product)
Engine type: IC engine (piston or wankel)
Take-off: Catapult
Landing: Arrested landing or parachute
Take-off: Catapult
Landing: Arrested landing or parachute
